MIG-250 Welding Machine with 5KGS Wire Feeder
Product Description
Product Description
Flux Core Welder MIG-250 welding machine 3 in 1 Welding Equipment with 5KGS Wire Feeder
Cored self-protection thin plate,spot welding
1. Machine is With IGBT HF inverter technology, with strong output power and reliable performance.
2.Machine is with wire checking function,the wire could be elongate to 20mm , easy to sart arc.
3.Machine can pre-set the current and voltage, easy to match welding parameters.
4.Machine is With Flux-cored /MIG/MMA 3 functional setttings, constant current and voltage output.
5. Machine is with VRD function, protecting workers out of electric shock.
6.Arc hardness adjustment, suitable for different materials and process requirments.
7.Machine is with advanced control circuit for no splash weld and good forming.
8.Machine is with reliable arc start for high speed spot weld.
9.Steady weld performance with thin wire, special for thin metal sheet weld to 0.5mm.
10. It is superior for welding thin metal sheet with 0.8mm weld wire
2.Machine is with wire checking function,the wire could be elongate to 20mm , easy to sart arc.
3.Machine can pre-set the current and voltage, easy to match welding parameters.
4.Machine is With Flux-cored /MIG/MMA 3 functional setttings, constant current and voltage output.
5. Machine is with VRD function, protecting workers out of electric shock.
6.Arc hardness adjustment, suitable for different materials and process requirments.
7.Machine is with advanced control circuit for no splash weld and good forming.
8.Machine is with reliable arc start for high speed spot weld.
9.Steady weld performance with thin wire, special for thin metal sheet weld to 0.5mm.
10. It is superior for welding thin metal sheet with 0.8mm weld wire
Technical Parameters
Model | MIG-200 | MIG-250 | |
Voltage range (V) | 1~ 220±15% | ||
Frequency (HZ) | 50/60 | ||
Rated input power (KVA) | 5.6 | 7.8 | |
Rated input current (A) | 25.7 | 35.4 | |
No-load voltage (V) | 54 | ||
Current adjustment range (A) | 60-200 | 60-250 | |
Voltage adjustment range (V) | 15.7-24 | 15.7-26.5 | |
Wire feeding speed (m/min) | 1.5-18 | ||
CO2 gas flow (L/min) | 10-15 | ||
Machine efficiency (%) | 85 | ||
Power factor | 0.82 | ||
Rated duty cycle（%） | 60 | ||
Duty cycle 100% | 155A/21.8V | 194A/23.7V | |
Welding wire diameter (mm) | 0.7-1.0 | ||
Welding electrode diameter (mm) | 2.0-3.2 | ||
Welding plate thickness (mm) | 4 | 5 | |
Protection level | IP23S | ||
Machine Weight (Kg) | 10 | 11 | |
Dimension (mm) | 460*220*370 | 460*220*370 | |
Detailed Images
Packing&Shipping
After Sales Service
1. One year warranty for whole machine
2. We have experienced after-sales service team,we can send installation video or file to customers and guid installation for easy operated machines and we can also arrange our engineers to visit customer's site for installation and training for complicated machines.
3. Full stock of spare parts and comsumbles are at competitive price.ottles in all shapes.
2. We have experienced after-sales service team,we can send installation video or file to customers and guid installation for easy operated machines and we can also arrange our engineers to visit customer's site for installation and training for complicated machines.
3. Full stock of spare parts and comsumbles are at competitive price.ottles in all shapes.
Company Introduction
FAQ
1. What kinds of after-sales service can your company supply? One year's warranty for whole Welding Machine. We will send spare parts for free during warranty period. About main board, we can supply life long service. 2. Can you supply OEM Service? Yes, we can supply OEM service. 3. What is deliver time? We will delivery the goods within 15-20 work days after received payment. 4. What is your payment term? We can accept T/T,Western Union,L/C,Aliexpress Escrow, Credit Card.
